• Energy Efficient: Low power consumption at 150 W.
• High Airflow: Up to 370 m³/h in Mixed Air mode.
• Stable Air Pressure: Consistent at 80 Pa across all modes.
• Quiet Operation: Noise level of only 40 dB.
• Lightweight: Fresh Air mode weighs just 6 kg.
• Multiple Modes: Offers Mixed Air, Fresh Air, and Circulation options.
• Custom Ducting: Compatible with 150 mm ducting size.
• Durable Construction: Built for long-lasting performance.
• Easy Maintenance: Accessible design for quick servicing.
• Versatile Applications: Suitable for residential, commercial, and industrial use.

Mode: Mixed Air

• Power: 150 W
• Airflow: 370 m³/h
• Air Pressure: 80 Pa
• Noise: 40 dB

Mode: Fresh Air

• Power: 150 W
• Airflow: 350 m³/h
• Air Pressure: 80 Pa
• Noise: 40 dB
• Weight: 6 kg
• Ducting Size: 150 mm

Mode: Circulation

• Power: 150 W
• Airflow: 350 m³/h
• Air Pressure: 80 Pa
• Noise: 40 dB

Product model	Outline dimension			Hook size		Flange size
	A	B	C	D	E	F	G
P-AQ-350	400	500	210	430	390	1	<150

Model	Type	Airflow	Voltage	Power
P-AQ-350	Class II	350 m3/h	220 V	150 W
Model	Purification	Noise	Weight	Size
P-AQ-350	>_99%	40db	6 KG	400 x 500 x 210



Model	Vol/Frequency (V/Hz)	Mode	Power (W)	Airflow (m³/h)	Air Pressure (Pa)	Noise (dB)	Weight (kg)	Ducting Size (MM)
									P-AQ-350	220/50	Mixed Air	150	370	80	40	6	150
Fresh Air	150	350	80	40
Circulation	150	350	80	40
